General Infromation
.High superior transparency(96% Over)
.Very little change in appearance when high temperature,humidity,and UV resistance
.Very high cohesive and peel strength for reliable bonding transparent substartes
.KN series are coated and conversted in a clean room
Application Ideas
.Touchscreens-for bonding optical film to Plastics, Glass etc.
.optical films Lamination for LCD, PDP Filter
Protect Construction
KN-6050 | KN-6075 | KN-6100 | KN-6125 | KN-6175 | |
Light Release（u） | 50 | 50/75 | 50/75 | 50/75 | 50/75 |
Acrylic Adhesive（u） | 50 | 75 | 100 | 125 | 175 |
Heavy Release（u） | 75 | 75 | 75 | 75 | 75/100 |
Techncal lnformation
6050 | 6075 | 6100 | 6125 | 6175 | ||||
光学特性 | 透光率 | % | 98 | 98 | 97 | 97 | 96 | |
Hzae | % | 1.49 | 1.49 | 1.49 | 1.49 | 1.49 | ||
雾度 | 1 | 1 | 1 | 1 | 1 | |||
b* | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | |||
剥离强度 |
粘着力 | PC | 300mm/min Kg/25mm | 1.5 | 1.8 | 2.0 | 2.0 | 2.5 |
ITO | 1.0 | 1.2 | 1.5 | 1.5 | 2.0 | |||
Glass | 1.6 | 2.0 | 2.5 | 2.5 | 2.7 | |||
高温高湿
| 高温 | 80℃/120ha | Nobubbles | Nobubbles | Nobubbles | Nobubbles | Nobubbles | |
高温高湿 | 80℃/85% | Good | Good | Good | Good | Good | ||
热冲击 | -30/80℃ | Good | Good | Good | Good | Good | ||
测试条件
基材：PET（50u）
剥离角：180
拉伸速度：300mm/min
测试环境：23℃*65%
